Water sports foldable towing apparatus and method
Utility Patent
A towing apparatus comprises a structural assembly extending between opposing first and second bases for pivoting between operating and stored positions. A locking assembly includes a pin in each base and a hook carried at opposing ends of the structural assembly. A cable is attached between the base and a spring within the structural assembly for biasing the structural assembly toward the operating position.
Water sports foldable towing apparatus and method
Utility Patent
A towing apparatus comprises a structural assembly extending between opposing first and second bases for pivoting between operating and stored positions. A locking assembly includes a pin in each base and a hook carried at opposing ends of the structural assembly. A cam is pivotally connected to the hook for movement between locked and released positions. In the locked position, the hook is secured to the pin for preventing rotation of the structural assembly. In the released position, the hook is spaced from the pin to permit rotation of the structural assembly. The hook is rotatable with the cam from the released position to adjacent the pin by rotation of a shaft and slidable along the pin into the locking position by a continued shaft rotation.
Towing structure for water sports
Design Patent
The ornamental design for a towing structure for water sports, as shown and described.
Towing structure for water sports
Design Patent
The ornamental design for a towing structure for water sports, as shown and described.
Bimini hardtop for watercraft
Design Patent
The ornamental design for a bimini hardtop for watercraft, as shown and described.
Telescopic Storage Device
*Patent Pending
the design consists of the visual features of shape, ornamentation and pattern of the Telescopic Storage Device shown in the drawings
